Awesome
Advantages
RescueBot is a fully automatic warning triangle with the latest autopilot technology.
It can reach the designated distance automatically and warn other approaching vehicles when an accident occurs.
It has three advantages:
Portable & One-click Opening
A rachet wheels & strings system enables the chassis and the triangle plates to simultaneously open.
Fully automatic substitute manual placement
Based on self-developed chassis and camera technology, fully automatic movement is achieved without manual placement.
Visual recognition mode
Tele-operation mode
GPS navigation mode
Intelligent alarm
Automatically uploads the location information of the accident location to the cloud, and real-time alarm
Automatically synchronizes the location information of the accident location to app users to warn the rear coming cars
Reliable
Details
Smart Triangle boasts a lightweight yet robust mechanical structure with acrylic panels, aluminum alloy components, carbon fiber suspension, and efficient TT motors.
​
Its electronic control system offers automatic placement, remote control, versatile modes, mobile integration, and a cloud-based warning system.
Hardware
In the event of an accident, our robot can automatically move to 150 meters to alert the coming cars
Convenient, Portable, Lightweight
The twin rocker design ensures one-click folding
​
Lightweight modeling: Use Carbon fiber high strength material and Hollowing out design
Through high-performance materials and well-designed construction, portability, lightweight and high strength are achieved
Software
In the event of an accident, our robot can automatically move to 150 meters to alert the coming cars
Remote Control
Automatic orientation: with Visual recognition of road and car-line patrol procedures
Remote operation: with Bluetooth remote control and Drive control programming
Intelligent Alarm APP
Remote control robot with Bluetooth
Update accident information in real time to inform users
Alarm accident information to the police
Car Line Detection
Based on the OpenCV , the acquired images are segmented semantically, so as to realize the car line detection. By applying randomized Hough transform with dynamic threshold, we are able to reduce calculation complexity and adapt to various road conditions.
Circuitry
Vision main board
A rachet wheels & strings system enables the chassis and the triangle plates to simultaneously open.
Control main board
The control module with GPS chip based on STM32 can receive data package from vision board to control motors.
Patent
The folding mechanical structure has been applied for invention patent protection
​
The control system has applied for software copyright
(Invention Patent, In Process)
(Software Copyright)
Special
Design
Specially designed for highway use, this robot features a stretchable robotic arm mounted on its body, enabling it to efficiently place barricades.
